UPVC Venturi Injector for Mixing Liquid Venturi with Valve BSP thread 1/2" 3/4" 1" 1.25" 1.5" 2" DGOzone
UPVC Venturi Injector for Mixing Liquid Venturi with Valve BSP thread 1/2" 3/4" 1" 1.25" 1.5" 2" DGOzone
Couldn't load pickup availability
UPVC Venturi Injector for Mixing Liquid Venturi with Valve BSP thread 1" 1.25" 1.5" DGOzone
#1 When you install venturi injector, please according to your water flow to select.
#2 Venturi injector is designed to be used with an ozone generator for water treatment.
#3 The unique mixed air chamber design and the strong mixed injection of water and air make the mixing well-distributed, complete, and make the bubbles exquisite, mixed with high efficiency, low energy consumption and long service life.
Installation
1. The venturi is usually installed horizontally, if installed vertically, the water must go from the bottom to the top. Never go from the top to the bottom, or it won't generate negative pressure.
2. the water tube diameter should be at least the same size as that of the venturi tube, so as to make sure water can go out freely without any resistance.
3. please choose the right size venturi according to your real application, without enough water flow, there won't form negative pressure.
If you have any questions, welcome to contact us any time.
