About Product:

2 Spool Directional Hydraulic Control Valve

The 2 spools hydraulic directional control valve 2P40 with joysticks. The adjustable release valve and durable cast iron body are easy to use. All spools are standard double acting with spring return in the neutral position.

Solid Construction

Excellent Performance

Spring Return

Inner Check/Relief Valve

Features:

1. 【DOUBLE ACTING】- Our hydraulic control valve is made for operating double-acting cylinders.

2. 【DURABLE QUALITY】- This hydraulic directional control valve comes with 2 spools and #8 SAE O-ring in/out ports, with cast iron construction for long-time use.

3. 【HIGH PERFORMANCE】- This hydraulic relief valve range can reach up to 3600 PSI and the maximum flow is up to 11 GPM.

4. 【SPRING RETURN】- All spool valves come with spring return, which can return to the neutral position.

5. 【WIDELY USED】- This hydraulic directional valve is suitable for small tractors, tractors loaders, log splitters, etc.

Specification:

• Max operating pressure : 3600psi

• Nominal flow : 11gpm (40l/min)

• Relief valve : Adjustable

• Center system : Open

• P, T, N port : 1/2" BSPP

• Dimension : 16.1''x5.1''x2.6'' (41x13x6.5 cm)

Package Includes

Product Details:
